Kr 5N, purity ≥99.999%
Royalchem
7439-90-9
| Product Name | Krypton Gas (Kr) 99.999% (5N) CAS 7439-90-9 | EC No. 231-098-5 Grade: 5N high purity · Form: compressed gas · Synonyms: high purity krypton, Kr 5N, electronic specialty gas, rare gas |
| Element / Atomic Number | Kr; atomic number 36 |
| Molar Mass | 83.798 g/mol |
| Physical Properties |
|
| Typical Specification (5N) | |
| Item | Limit |
| Krypton (Kr) | ≥ 99.999% |
| Hydrogen (H2) | ≤ 0.3 ppm |
| Oxygen + Argon (O2 + Ar) | ≤ 1.5 ppm |
| Nitrogen (N2) | ≤ 2 ppm |
| Carbon monoxide (CO) | ≤ 0.3 ppm |
| Carbon dioxide (CO2) | ≤ 0.1 ppm |
| Methane (CH4) | ≤ 0.05 ppm |
| Xenon (Xe) | ≤ 0.1 ppm |
| Moisture (H2O) | ≤ 2 ppm |
| Carbon tetrafluoride (CF4) | ≤ 0.5 ppm |
| Key Applications |
|
| Cylinder Packaging | High-pressure steel cylinders. Typical: 40 L / 50 L water capacity; valve outlet CGA 580 / DIN 6 / JIS or other standards on request. Cylinder size, fill volume and pressure, valve outlet, cylinder material, return arrangements and available quantity are confirmed on the quotation and order. Please state destination, end use and required valve standard when enquiring. |
| Storage & Handling | Non-flammable, but a high-concentration leak displaces oxygen and can cause asphyxiation. Keep cylinders upright and secured with valve protection in place, in a cool, well-ventilated area away from heat and direct sunlight. Use a regulator rated for the cylinder pressure with backflow prevention; test oxygen levels before entering potentially oxygen-deficient areas. |
| Transport | UN 1056, proper shipping name “Krypton, compressed”, Class 2.2 non-flammable, non-toxic gas, no packing group. Final shipping name, labels and declarations are subject to the batch SDS, fill state and destination regulations. |
| What does krypton 99.999% (5N) mean? | Krypton content of at least 99.999% by the specified test method. Suitability for a given process also depends on the individual trace-impurity limits (H2O, O2, N2, CF4, hydrocarbons) and the batch COA. |
| What is the molar mass of krypton? | About 83.798 g/mol — heavier than argon (39.95) and lighter than xenon (131.29). |
| Is krypton flammable or toxic? | No. It is non-flammable, chemically inert and non-toxic, but it is a compressed gas (UN 1056, Class 2.2): cylinders may rupture if heated, and a large leak can cause oxygen-deficiency asphyxiation, so ventilate and follow high-pressure gas handling rules. |
| Krypton or xenon — which should I use? | Xenon is heavier with a lower ionization energy and is preferred for high-end propulsion and advanced etch; krypton is cheaper and is the standard choice for insulating glass, KrF excimer lasers and lighting, and a cost alternative for Hall thrusters. Royalchem supplies both and can advise by application. |
| Can you provide COA, SDS and cylinder documents? | Yes. Batch COA, SDS, specification confirmation and cylinder / dangerous-goods shipping documents are provided for each order. |
